Frames and Machines
Get link
Facebook
X
Pinterest
Email
Other Apps
-
Truss and it's Types:
Truss is a structure of connected elements forming triangular units, and a bridge whose load-bearing superstructure is composed of a truss.
There are three types of truss and they are:
1. Simple Truss:
A truss is a structure composed of slender members joined together at their end points.
2. Planar Truss:
Planar truss lies in single plane and typically used in parallel to form roofs and bridges.
3. Space Truss:
A space Truss consists of members joined together at their ends to form a stable three-dimensional structure.
Assumptions for Designing Truss:
To design the truss, we have two assumptions:
All loadings are applied at the joints.
The members are joined by smooth pins.
The Method of Joints:
In order to analyze or design a truss, it is necessary to determine the forces in each of its members. Method of joints consists of fool owing steps:
Truss is in equilibrium so does its joints.
Draw Free-body diagrams for each joint.
Apply the force equilibrium equations and obtain the required ones.
ΣFx = 0
ΣFy = 0
The Method of Sections:
By using the method of sections, you need to follow the instructions below:
Truss is in equilibrium so does the segments of truss.
Draw free Body diagram indicating all forces.
Cut the free Body diagram into its simple parts.
Apply the equilibrium equations to find the required forces and moments.
ΣFx = 0
ΣFy = 0
ΣMo = 0
Zero Force Members:
Zero-force members in a truss members which do not have any force in them. Zero-force members are used to increase the stability of the truss during construction and to provide added support of the loading is changed.
Frames:
Frames used to support loads which are often composed of pin-connected multi-force members that are subjected to more than two forces.
Machines:
Machines contain moving parts which are often composed of pin-connected multi-force members that are subjected to more than two forces.
