Techniques to Examine Crystal Defects
Get link
Facebook
X
Pinterest
Email
Other Apps
-
Microscopic Techniques
It is defined as, "techniques used to examine structural elements and defects in crystalline materials".
Microstructure ↠ combination of crystal structure + grain size + defects in crystal structure + phase + impurities.
Microscopy ↠ used for the investigation of microstructural features (instruments).
Applications of microscopy and micro-structure are:
Ensure association between the properties, structures and defects.
To predict property of material (after relationship created).
To design alloys with new property combination.
Check material has been properly heat treated.
To study various mode of mechanical fracture.
Types of Microscopy
1. Optical Microscopy
It is defined as, "microscopy in which visible light and system of lenses to magnify images of small samples". Upper limit magnification is 2000x.
It consists of two major systems, which are
Magnification System ↠ have lenses to magnify.
Illuminating System ↠ have light and camera for capturing images.
Metallographic investigation (optical microscopy of metals) consist of following steps:
Sectioning ↠ cutting of material to observe a structure of large crystal structure.
Grinding ↠ to remove buds over the surfaces.
Polishing ↠ to further smoothen the surface.
Etching ↠ workpiece is dipped in Nitric Acid to highlight boundaries.
2. Electron Microscopy
It is defined as, "microscopy in which image of investigated structure is formed using beams of electrons".
Magnification power is smaller than that of optical microscopy.
