Energy, Energy Transfer and Energy Analysis
Get link
Facebook
X
Pinterest
Email
Other Apps
-
Forms of Energy
Macroscopic Form of Energy:
The energy which a body posses by its whole that it is measured with respect to some outside reference frame.
Microscopic Form of Energy:
The energy which is related to the molecular structure of a system and a degree of molecular activity. These energies are independent of the outside reference frame.
kinetic and Potential Energies:
Kinetic energy is defined as the energy related to motion of the body.
Potential energy is defined as the energy associated with the position of the body.
Total Energy of a System:
In the absence of magnetic, electric and surface tension effects, the total energy of a system consist of sum of internal, potential and kinetic energies.
Volume, Mass and Energy Flow Rate:
Volume flowing through area per unit time is called Volume Flow Rate.
Amount of mass flowing through a cross section per unit time is called Mass Flow Rate.
Energy associated with a fluid at mass flow rate is called Energy Flow Rate.
Mechanical Energy:
The form of energy that can be converted to mechanical work completely and directly by a device. Like kinetic energy, potential energy, pressure, e.t.c.
Energy Transfer by Heat:
It is a boundary phenomena in which energy transfer take place due to the difference in temperature of bodied.
Energy Transfer by Work:
Energy transfer take place due to the force acting a distance.
Shaft Work or Mechanical Work:
Spring Work:
It is a mechanical work in which work is done due to spring.
First Law of Thermodynamics:
Law of Conservation of Energy states that;
Energy can neither be created nor be destroyed but it can be transfered from one form to another.
